Howo TX 440hp 8x4 dump truck 24m3
Howo TX 440hp 8x4 dump truck 24m3 Specifications & Features| Model | ZZ3317N286HE1 | Brand | Howo | | Drive model | 8x4 | Wheel base | 1800+2825+1350mm | | Engine model | Sinotruk MC11.44-50 | Gearbox | Sinotruk HW25712XSJ | | Rear axle ratio | 5.26 | Dimension (LxWxH) | 8960x2550x3490mm | | Wheel track | 2022/2022mm+1860/1860mm | Tare weight | 15500kg | | Payload | 15370kg | Condition | Brand new | | Product Parameters |
|
|
| | |
|
|
| | Engines | Engine model | Sinotruk MC11.44-50 |
| | No. of cylinders | 6 |
| | Fuel type | Diesel |
| | Engine capacity | 10.518L |
| | Emission standard | Euro 5 |
| | Max horsepower | 440hp |
| | Max power | 324kW |
| | Maximum torque | 2100N·m |
| | Gearboxes | Gearbox model | Sinotruk HW25712XSJ |
| | Gear shifting method | Manual |
| | Forward gears | 12 |
| | Reverse gears | 2 |
| | Chassis | Front axle allowable load | 6500/7000kg |
| | Rear axle allowable load | 18000kgx2 |
| | Rear axle ratio | 5.26 |
| | Cargo box | Cargo box Dimension (LxWxH) | 6500x2350x1500mm |
| | Tire | Tire numbers | 12 |
| | Tire size | 12.00R20 18PR |
|
|
