Shacman F3000 Dump Truck For Sale 6x4 430HP SX5250ZLJDB3842B
Shacman F3000 Dump Truck For Sale 6x4 430HP SX5250ZLJDB3842B Specifications & FeaturesBasic Info| Model | SX5250ZLJDB3842B | Brand | Shacman |
|---|
| Drive model | 6x4 | Wheel base | 3975+1400mm |
|---|
| Engine model | Weichai WP12.430E50 | Gearbox | FAST 12JSD200T-B |
|---|
| Rear axle ratio | 5.262 | Dimension (LxWxH) | 8600x2550x3450mm |
|---|
| Wheel track | 2036mm+1860/1860mm | Tare weight | 12500kg |
|---|
| Payload | 12370kg | Condition | Used |
|---|
Product Parameters| Engines | Engine model | Weichai WP12.430E50 |
|---|
| No. of cylinders | 6 | | Fuel type | Diesel | | Engine capacity | 11.596L | | Emission standard | Euro 5 | | Max horsepower | 430hp | | Max power | 316Kw | | Maximum torque | 2060N·m | | Gearboxes | Gearbox nodel | Fast 12JSD200T-B |
|---|
| Gear shifting method | Manual | | Forward gears | 12 | | Reverse gears | 2 | | Chassis | Frame size | 850×300 (8+7)mm |
|---|
| Front axle allowable load | 7000kg | | Rear axle allowable load | 2x18000kg | | Rear axle ratio | 5.262 | | Number of leaf springs | 10/12 | | Cargo box | Cargo box Dimension (LxWxH) | 5800x2350x1500mm |
|---|
| Thickness of the bottom/side panel | 16/14mm | | Tire | Tire numbers | 10 |
|---|
| Tire size | 12.00R20 16PR | | Brakes | ABS (Anti-lock Braking System)、Hydraulic retarder |
|---|
|
